The SB series features ultra-lightweight prefabricated barriers, designed and certified for temporary use in work zones. The efficient transport and quick installation of the barriers, combined with the certified retention class up to H1.
SB bollards have a wide range of application including highway construction sites, temporary traffic diversion, bypasses and more.
Through the special transition elements SB barriers can be seamlessly connected to other types of barriers.
SB temporary barriers are tested according to EN 1317 for all performance categories (T1/T3/N2/H1) and are CE marked
For retention classes T1, T3 & N2 the barriers weigh only 125 kg/m, for N2 & H1 they weigh 206 kg/m and for H1|W4 & T3|W1 they weigh 288 kg/m.
With a bearing base width of less than 30cm and minimal impact displacement, the use of SBs allows the creation of narrow working zones.
| TYPE | PERFORMANCE | INSTALLATION METHOD | ANCHORATION METHOD | PROTECTION | DIMENSIONS |
|---|---|---|---|---|---|
| DB 65S | H1 | W6 | B | surface mounted | no anchoring | double sided | 0,65 / 0,39 / 6,00 m |
| SB 70B | H1 | W4 | B | surface mounted | no anchoring | double sided | 0,70 / 0,30 / 6,00 m |
| SB 70B | T3 | W1 | A | surface mounted | no anchoring | double sided | 0,70 / 0,30 / 6,00 m |
| DB 80 | N2 | W3 | B | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 6,00 m |
| DB 80 | N2 | W4 | B | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 4,00 m |
| DB 80 | H1 (L1) | W4 | B | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 6,00 m |
| DB 80 | H1 | W6 | B | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 4,00 m |
| DB 80F | T3 | W2 | A | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 6,00 m |
| DB 80F | N2 | W2 | B | surface mounted | no anchoring | double sided | 0,80 / 0,60 / 6,00 m |
| DB 80E | N2 | W3 | B | surface mounted | no anchoring | double sided | 0,85 / 0,60 / 6,00 m |
| DB 80AS-E | T3 | W2 | A | surface mounted | no anchoring | single sided | 0,92 / 0,50 / 6,00 m |
For more information contact us at info@armosprokat.gr
